Slatwall Panel Sizes

Standard slatwall sections typically measure 96 inches (8 feet) in length with seamless hidden-fastener construction. Steel systems are also available in 32-square-foot section configurations. Panel height and width can often be customized to fit specific gondola, wall, or endcap dimensions upon request.

Slat spacing options range from 1 inch to 3 inches on center, including 1 inch, 1-3/8 inch, 1-1/2 inch, 2 inch, and 3 inch configurations. Narrower spacing suits smaller accessories and frequent merchandise changes, while wider spacing accommodates heavier or bulkier display hooks and shelving.

Both steel and aluminum slatwall panels are rated to hold over 50 lbs per linear foot, making them suitable for heavy-duty retail applications such as hardware, sporting goods, and general merchandise displays that require sturdy support for hooks, shelves, and brackets.

Panels are available in heavy-gauge steel or aluminum. Aluminum panels contain over 50% recycled content and are LEED-certified, while steel panels are formed and welded for added rigidity. Both are fire code compliant and more durable than conventional MDF-based slatwall alternatives.

Yes. Custom lengths, colors, and powder-coated finishes are available beyond standard sizing. Retailers can also select from various trim options, including outside and inside 90-degree and 45-degree trims, to fit unique wall configurations and store layouts.

Standard finishes include Dove Gray, Black, Beige, Platinum, White, Galvanized, Candy Apple Red, Candy Apple Blue, Swirl, Raw Mill, and Clear Anodize, depending on the material. Custom color matching is also available to align slatwall panels with specific brand or store design requirements.
